Adixen ASM GRAPH D+ - Parameter Function Keys

2 /3
C 110
GB
01361
- Edition 03 - September
04
Operating principle of the control panel
Parameter function keys
Standard control panel
Control panel with graphic
inter face
(option/accessor y)
• To access to the parameter to be changed, there are
up to 4 function keys available on the alphanumeric
display ( , , and
F4
). Only one
parameter
key can be activated at a time.
• No function keys : to access to the
parameter to be changed, press on the
parameter value. Only one parameter
value can be activated at a time.
Press = press on the 1st line red value
Similarly:

2nd line,

3rd line ;
F4

4th line
Note: In the user’s manual, all the functions are explained with to
F4
function keys.
• The LED indicator is ON when the
corresponding function key is available:
the modification of the parameter
displayed on the line is authorized.
• Press the function key: the LED indicator
will flash: the modification can be
performed. It is possible to escape and
reset the previous value by pressing
RESET key or the active menu selection
key .
• Once the parameter is modified,
pressing the function key again
validates it: the LED indicator remains
ON and stops flashing.
• The value parameter is red when the
corresponding parameter is available
for modification.
• Press on the value: a arrow appears .
the modification can be per for med.
PRESSURE UNIT: mbar
ZERO ROUGHING: yes
TEST MODE: normal
START TEMPO: 00:10
It is possible to escape and reset the
previous value by pressing RESET key or
the active menu selection key .
• Once the parameter is modified,
pressing the red value again validates
it: the arrow disappears .
