C 301
Basic internal calibration of the leak
detector
5 /5
GB 00969 -
Edition
06 -
June
08
6
End of the Close the valve of the calibrated leak (if there i s one).
process
These 2 screens appear alternately.
PLEASE,CLOSE He LEAK
OK -> press NEXT
ON TEST PORT!
OK -> press NEXT
Validate the operation.
NEXT
Note: If these operations are not done within a
minute after these screens display, the calibration
is automatically stopped. A
message informs the
operator of this stop.
When the calibration is complete, the unit is ready
to start a cycle.
READY FOR CYCLE
...
...
...
STDBY
Note: it is possible to start a test cycle after a
calibration failure.
