Adixen ASM GRAPH D+ - Page 145

C 410
Headphone and loudspeaker
3 /3
P0307 board
Strap on
ST3/ST2
Sub
D
9
pins
(printer
plug)
Int
Internal loudspeaker
active
•
•
ST3
•
•
ST2
No plug connected
•
•
ST3
•
•
ST2
1 2 3 4 5
6 7 8 9
Int
Internal loudspeaker
active + headphone
connected
•
•
ST3
•
•
ST2
1 2 3 4 5
6 7 8 9
Int
Internal loudspeaker
not active
+
headphone
connected
•
ST3
•
•
ST2
1 2 3 4 5
6 7 8 9
Int
Ext
Internal loudspeaker
active + Exter nal
loudspeaker connected
•
•
ST3
•
•
ST2
1 2 3 4 5
6 7 8 9
Int
Ext
Internal loudspeaker
not active
+
External loudspeaker
connected
•
ST3
•
•
ST2
1 2 3 4 5
6 7 8 9
GB 00633
-
Edition 03
- June
08
•
•
