Adtech ADT-DK300A User Manual

BZ001M056A ADT‐DK300A/400A Engraving Machine

87
CMR/CMD=P/(L×1000)
CMR:gearrationumerator
CMD:gearratiodenominator
P:Pulsescorrespondingtoonerotationofthemotor
L:Machinetoolmovementcorrespondingtoonerotationofthemotor
(mm)
CMD/CMR is the  pulse equivalent actually, i.e. the motion distance
corresponding toeverypulse(unit:0.001mm).
Ex1:the
motorrotatesonecycleevery5000pulses,andthemachine
toolmoves5mmwhenthemotorrotatesone cycle,then
CMR/CMD=5000/(5*1000)=1/1
Then,CMR=1,CMD=1,thepulseequivalentis0.001mm
Ex2:themotorrotatesonecycleevery5000pulses,andthe machine
toolmoves10mmwhenthemotor
rotatesonecycle,then
CMR/CMD=5000/(10*1000)=1/2
Then,CMR=1,CMD=2,thepulseequivalentis0.002mm
009 
XFastSpeed(mm/min)
010 
YFastSpeed(mm/min)
011 
ZFastSpeed(mm/min)
012 
4FastSpeed(mm/min)
013 
XStartupSpeed(mm/min)
014 
YStartupSpeed(mm/min)
015 
ZStartupSpeed(mm/min)
016 
4StartupSpeed(mm/min)
017 
XAcceleration(Kpps)
018 
YAcceleration(Kpps)
019 
ZAcceleration(Kpps)
020 
4Acceleration(Kpps)
Range : 1~200000,1~200000,1~8000
Unit : mm/min,mm/min,Kpps
Authority : Operationadminorhigher
Default : 3000,100,1000
Effectivetime : Instant
Note : This parameter is the trapezoid acceleration/deceleration setting and
