BZ001M056A๎ ADTโDK300A/400A๎ Engraving๎ Machine๎
๎
88
used๎for๎GOO๎instruction๎
About๎ start๎ speed,๎ 1โ2๎ rotation๎ motor๎ speed๎ is๎ recommended๎ for๎ step๎
motor;๎as๎above,๎the๎machine๎tool๎moves๎5mm๎when๎the๎motor๎rotates๎
one๎ cycle,๎ and๎ the๎ speed๎ is๎ 5โ10mm/sec๎ (300โ600mm/min).๎ For๎ servo๎
motor,๎ the๎ start๎ and๎ stop๎ shouldnโt๎ have๎ vibration.๎ If๎ this๎ speed๎ is๎ too๎
high,๎it๎will๎cause๎vi bration๎during๎motion,๎and๎the๎step๎motor๎will๎be๎out๎
of๎step.๎If๎the๎machine๎tool๎vibrates๎when๎starting๎and๎stopping,๎you๎can๎
reduce๎the๎acceleration.๎
The๎acceleration๎and๎start๎speed๎also๎affect๎manual๎speed,๎home๎speed,๎
etc.;๎
021๎ ๎
X๎Soft๎PosLimit+( mm)๎
022๎ ๎
X๎Soft๎Po sLimitโ(mm)๎
023๎ ๎
Y๎Soft๎PosLimit+(mm)๎
024๎ ๎
Y๎Soft๎PosLimitโ(mm)๎
025๎ ๎
Z๎Soft๎PosLimit+(mm)๎
026๎ ๎
Z๎Soft๎PosLimitโ(mm)๎
027๎ ๎
4๎Soft๎PosLimit+(mm)๎
028๎ ๎
4๎Soft๎PosLimitโ(mm)๎
๎๎Range๎๎๎ :๎โ9999~9999๎
๎๎Unit๎๎๎ :๎ mm๎
๎๎Authority๎ :๎ Operation๎admin๎or๎higher๎
๎๎Default๎ :๎ Maximum๎positive/negative๎value๎
๎๎Effective๎time๎ :๎ Instant๎
๎๎Note๎ :๎ Generally,๎the๎machine๎tool๎ has๎hard๎limit๎ signal.๎In๎ this๎case,๎software๎
limit๎ isnโt๎ required.๎ Please๎ set๎ the๎ positive๎ limit๎ to๎ +9999.999,๎ and๎
negative๎limit๎to๎โ9999.999.๎
If๎ hard๎ limit๎ switch๎ isnโt๎ installed,๎ please๎ use๎ soft๎ limit,๎ which๎ uses๎
machine๎ tool๎ coordinate๎ system๎ as๎ the๎ base๎ point.๎ Positive๎ limit๎ and๎
negative๎limit๎are๎subject๎to๎actual๎distance๎(unit:๎mm).๎
Since๎ soft๎ limit๎ decelerates๎ and๎ stops๎ at๎ the๎ limit๎ point,๎ it๎ may๎ exceed๎
the๎set๎distance,๎which๎depends๎on๎acceleration
๎time๎and๎speed.๎Please๎
keep๎certain๎margin๎when๎setting๎this๎parameter.๎
๎
029๎ ๎
Inp๎Speed(mm/min)๎
030๎ ๎
InpStartSpeed(mm/min)๎
