ADTRAN Total Access 600R System Manual

Section 4 User Interface Guide Total Access 600R System Manual
106 © 2002 ADTRAN, Inc. 61200600L1-1A
SECURITY > FILTERS > FILTER DEFINES > PATTERN FILTER DEFINES
The pattern filter is applied to bridge packets only. That is any packet which is forwarded by the bridge
functionality of the unit. Up to 32 pattern defines can be specified.
NUM
Indicates the entry number in the MAC Filter Defines table.
NAME
Identifies the filter entry. Default is no entry in NAME field.
SRC ADDR
48-bit MAC source address used for comparison. Values are in hexadecimal format. Default is
00:00:00:00:00:00.
SRC MASK
Bits in the MAC source address which are compared. Values are in hexadecimal format. Default is
00:00:00:00:00:00.
DEST ADDR
48-bit MAC destination address used for comparison. Values are in hexadecimal format. Default is
00:00:00:00:00:00.
DEST MASK
Bits in the MAC destination address used for comparison. Values are in hexadecimal format. Default
is
00:00:00:00:00:00.
TYPE
16-bit type field used for comparison. Values are in hexadecimal format. Default is 00:00.
TYPE MASK
Bits in the type field used for comparison. Values are in hexadecimal format. Default is 00:00.
NUM
Indicates the entry number in the Pattern Filter Defines table.
NAME
Identifies the filter entry. Default is no entry in NAME field.
