Total Access 600R System Manual Section 4 User Interface Guide
61200600L1-1A © 2002 ADTRAN, Inc. 107
SECURITY > FILTERS > FILTER DEFINES > IP FILTER DEFINES
The IP filter defines apply to any IP packet, whether it is routed or bridged. Up to 32 IP defines can be
specified.
OFFSET
Offset from beginning of packet of where to start the pattern comparison. Default is 0.
PATTERN
64 bits used for comparison. Values are in hexadecimal format. Default is 00:00:00:00:00:00:00:00.
MASK
Bits in the pattern to be compared. Values are in hexadecimal format. Default is
00:00:00:00:00:00:00:00.
NUM
Indicates the entry number in the IP Filter Defines table.
NAME
Identifies the filter entry. Default is no entry in NAME field.
SRC ADDR
IP address compared to the source address. Value is in dotted decimal format. Default is 0.0.0.0.
SRC MASK
Bits which are used in the source comparison. Value is in dotted decimal format. Default is 0.0.0.0.
DEST ADDR
IP address compared to the destination address. Value is in dotted decimal format. Default is 0.0.0.0.
D
EST MASK
Bits which are used in the destination comparison. Value is in dotted decimal format. Default is
0.0.0.0.
S
RC PORT
IP source port number used for comparison. Value is in decimal format. Range: 0 TO 65535. Default
is
0.
