Page #130 background imageLoading...
Page #130 background image
130 © 2002 ADTRAN, Inc. 61200600L1-1A
Section 5 DLP-001 Total Access 600R System Manual
DLP-001
1. Connect a VT100 terminal to the unit.
2. Connect a PC emulating a VT100 terminal to the unit.
3. Most personal computers or laptops can run communications software that will emulate a VT100
terminal. Windows programs such as Terminal
©
or Hyperterminal
©
are two such examples in the
Windows format. However, there are many other adequate, commercially available software packages
which will allow your PC or laptop to emulate a VT100 terminal. Certain configuration items must be
set on a PC or laptop for it to act as a VT100 terminal for the unit.
4. Press <Enter> or <Ctrl + R> until the Login menu appears on screen.
You are now ready to log in to the unit, as described in DLP-002, Logging in to the System.
Follow-up Procedures
Once this procedure is complete, return to the procedure which referred you to this DLP and continue with
the tasks indicated there.
Perform Steps Below in the Order Listed
Set the parameters of the VT100 terminal to:
9600 baud rate
8 data bits
No parity
1 stop bit
No flow control
If the terminal has a parallel setting, disable it and use serial port.
Plug the RJ-45 male end of the data cable into the CRAFT port on the rear of the unit by
using the ADTRAN-proprietary DB-9 to RJ-45 adapter. Make the connection to the VT100
terminal as appropriate for your equipment.
Set the PC for direct connect on the appropriate com port (instead of dial-up connection).
Set the parameters of the communications software to:
9600 baud rate
8 data bits
No parity
1 stop bit
No flow control
Plug the RJ-45 male end of the data cable into the CRAFT port on the rear of the unit by
using the ADTRAN-proprietary DB-9 to RJ-45 adapter. Make connection to the PC or lap-
top as appropriate for your equipment.
A VT100 terminal program is provided with the ADTRAN Utilities.
