Section 4 User Interface Guide Total Access 600R System Manual
90 © 2002 ADTRAN, Inc. 61200600L1-1A
PRIVATE ADDRESS MODE
(This option is only available when NAT PORT TRANSLATION is enabled.) The private IP
address can be specified to steer certain protocols and ports to specific servers in the private
network. Likewise, internal hosts can be steered to certain servers on the public network. A
new request from the public network matching this entry’s public parameters will be
dropped if this mode is set to
ANY INTERNAL. Choices are SPECIFIED and ANY INTERNAL.
Default is
ANY INTERNAL.
P
RIVATE ADDRESS
(This option is only available when NAT PORT TRANSLATION is enabled and PRIVATE
A
DDRESS MODE is set to SPECIFIED.) Default is 0.0.0.0.
P
RIVATE PORT MODE
(This option is only available when NAT PORT TRANSLATION is enabled. However, it will
not be available if P
ROTOCOL MODE is set to ICMP; ANY (TCP, UDP, or ICMP); ALL;
S
PECIFIED; or NONE.) The private destination port associated with this entry can be specified
to add more control over certain types of traffic. Leave as
ANY PORT to cover all port types.
Choices are
ANY PORT and SPECIFIED. Default is ANY PORT.
P
RIVATE PORT
(This option is only available when NAT PORT TRANSLATION is enabled and PRIVATE PORT
M
ODE is set to SPECIFIED. However, it will not be available if PROTOCOL MODE is set to
ICMP; ANY (TCP, UDP, or ICMP); ALL; SPECIFIED; or NONE.) Default is 0 (decimal).)
TRANSLATE BODY
(This option is only available when NAT PORT TRANSLATION is enabled.) When set to YES,
the application payload in the packet is scanned for occurrences of the private/public IP
address in binary or ASCII form. Set this to
NO (default) for applications where this will
cause problems.
NAT VIEW
Shows the protocols that are actively being translated.
ENTRY
Indicates the entry number in the NAT VIEW table.
PRIV ADDR
(This option is only available when NAT PORT TRANSLATION is enabled.) This shows the
private address of the host that the entry is used for.
PUB ADDR
(This option is only available when NAT PORT TRANSLATION is enabled.) This shows the
public address this entry is using for its NAPT.
