GENERAL INFORMATION
1-11
SSB AM noise: For 20 kHz offset (typical values), measured at levels > 0 dBm:
CW/IQ
≤ 3 GHz −130 dBc/Hz
≤ 6 GHz −125 dBc/Hz
Typical AM noise at 1 GHz
RF leakage:
< 0.5 µV PD at the carrier frequency into a single-turn 25 mm diameter loop, 25 mm or
more from the case of the signal generator, for carrier frequencies < 3 GHz
Wideband noise: Applicable for all carrier levels at offsets > 5 MHz and < 50 MHz excluding thermal noise
(23°C ± 5°C):
RF mode
≤ 375 MHz ≤ 3 GHz ≤ 6 GHz
Power
< −138 dBc/Hz < −142 dBc/Hz
(typ −148 dBc/Hz)
< −136 dBc/Hz
Noise
< −138 dBc/Hz < −142 dBc/Hz
(typ −148 dBc/Hz)
< −136 dBc/Hz
ACP
< −135 dBc/Hz < −140 dBc/Hz < −134 dBc/Hz
