1.1. Electrical Specifications
The electrical specifications for the HEXRC drive chassis are listed in Table 1-3 and the electrical
specifications for the servo amplifiers in Table 1-4 and 1.1.
Table 1-3: Chassis Electrical Specifications
Description Specifications
Total Motor Power Supply 80 V @ 600W
Input
Current
100 VAC 10 A Maximum
115 VAC 10 A Maximum
200 VAC 6 A Maximum
230VAC 5 A Maximum
Inrush Current 100 A @ 254 VAC
Leakage Current <1/5 mA @ 60 Hz / 254 VAC
AC Power Input
AC input (factory configured): AC Hi, AC Lo, Earth Ground ( ),
l 100 VAC (90-112 VAC, 49-63 Hz)
l 115 VAC (103-127 VAC, 49-63 Hz)
l 200 VAC (180-224 VAC, 49-63 Hz)
l 230 VAC (207-254 VAC, 49-63 Hz)
Auxiliary Power Outputs
+5 V is provided on all axis feedback connectors for encoder, Hall, and limit
power.
Protection
l Power switch / breaker (10 A, Supplemental Protection only).
l Fuses on motor bus supply transformer.
l Bus supply inrush current limit during power-on.
Indicator (Power) Power switch contains a power-on indicator.
