Aerotech A3200 - Table 1-5: Unit Weight; Dimensions

HEXRCHardware Manual Introduction
ON
OFF

AEROTECH.
COM
0
A
HEX RC
Powered by
3
2
0
USB
MOTOR / FEEDBACK
DIGITAL / ANALOG IO MPGA
DVI
USB2 USB3 ETHERNET FIREWIRE
ESTOP
1 2
1 2
3 4 5 6
447.6 [17.62]
444.5 [17.50]
110.6 [4.35]
82.0 [3.23]
66.2 [2.60]
37.7 [1.48]
94.7 [3.73]
139.3 [5.48]
7.1 [0.28]
(4 PLS.)
177.0 [6.97]
8.3 [0.33] (TYP.)
Drawing Number: 620E1422-
463.5 [18.25]
466.0 [18.35]
476.2 [18.75]
482.6 [19.00]
428.5 [16.87]
535.9 [21.10]
41.7 [1.64]
570.9 [22.47]
Figure 1-3: Dimensions
Table 1-5: Unit Weight
Description Weight
Chassis Weight (typical) 25 kg
8 Chapter 1 www.aerotech.com
