7713395 R2 47
• The cross auger system combines the dried grain from the two main discharge augers and transfers it to a
single discharge output that can be supplied with a left-hand discharge, right-hand discharge, or a center
discharge.
• If needed, the orientation of the discharge (RHT, LFT, CTR) can be changed. Contact your NECO dealer.
The following steps describe how to close the clean-out doors on the auger system:
1. Close the outer clean-out door first.
Figure 47. Close the outer door first
2. While holding the outer door in place, close the inner door until it overlaps with a snug fit.
Figure 48. Adjust the latch
3. Adjust the latch to a reasonable tension.
4. Put the latch’s loop into the inner door’s hook.
5. Secure by pushing the draw latch closed.
Figure 49. Push the latch closed
Note
To open the doors, simply reverse the previous steps (excluding the tension adjustment).
CONTINUOUS MIXED-FLOW GRAIN DRYER WITH COMMANDER CONTROL SYSTEM 3. FEATURES
