5 Saving, Recalling, and Printing Data
120 Agilent 1000B Series Oscilloscopes User’s Guide
To save to or recall from internal storage:
a Press Internal.
b In the Internal menu, press Location.
c Continue pressing the Location softkey or turn the entry knob to
select the desired internal storage location.
The “(N)” suffix shows that nothing has been saved to the location.
The “(S)” suffix shows waveforms have been previously saved to the
location.
d Press Save or Recall.
To save to or recall from external storage (when a USB drive is
connected to the front panel USB host port):
a Press External.
b Use the disk manager dialog to navigate to the folder where you
want to save the file or to select the file you want to load (see “To
navigate the directory hierarchy” on page 123).
c In the External menu:
To save the setup, press New File, enter the filename (see “To edit
folder/file names” on page 124), and press Save.
To recall the selected setup (.stp file), press Recall.
To save screens to BMP or PNG format files
You can save oscilloscope display screens (in BMP or PNG format) to an
external USB drive when it is connected to a rectangular USB host port.
1 Press [Save/Recall].
2 In the Storage menu, press Storage.
3 Continue pressing the Storage softkey or turn the entry knob to
select one of:
8-Bitmap 8- bit BMP format.
24-Bitmap 24- bit BMP format.
PNG Portable Network Graphics format.
