1Getting Started
30 Agilent 1000B Series Oscilloscopes User’s Guide
Step 8. Become familiar with the oscilloscope display
Channel 1 Status,
DC coupling, 500 mV per division
Timebase
Status,
500 us per
division
Channel 1
Reference
Acquisition
Status
Waveform
Trigger,
rising edge,
channel 1,
1.56 V
Waveform window
position in memory
Trigger position
in memory
Trigger position in
waveform window
Figure 7 Oscilloscope Display
