Saving, Recalling, and Printing Data 5
Agilent 1000B Series Oscilloscopes User’s Guide 127
Printing Screens
You can print oscilloscope display screens to:
• A PictBridge compliant printer connected to the (square) USB device
port on the oscilloscope’s back panel.
Figure 51 USB Device Port
