Capturing Data 3
Agilent 1000B Series Oscilloscopes User’s Guide 83
To store recorded waveforms
To store recorded waveforms:
1 Press [Acquire].
2 In the Acquire menu, press Sequence.
3 In the Sequence menu, press Mode.
4 Continue pressing the Mode softkey or turn the entry knob to select
“Storage”.
To select the start frame
1 In the Sequence menu ([Acquire] > Sequence > Mode=Storage), press
Start Frame.
2 Turn the entry knob to select a number from l to 1000.
To select the end frame
1 In the Sequence menu ([Acquire] > Sequence > Mode=Storage), press
End Frame.
2 Turn the entry knob to select a number from l to 1000.
To select internal/external recording storage location
1 In the Sequence menu ([Acquire] > Sequence > Mode=Storage), press
Location to toggle between Internal and External.
To save a recording
1 In the Sequence menu ([Acquire] > Sequence > Mode=Storage), press Save.
2 If the External location has been selected, use the Disk Manager to
name and save the waveform recording file. See “Using the Disk
Manager” on page 122.
Internal Recordings are saved and loaded from oscilloscope
internal memory.
External Recordings are saved, loaded, exported, and imported
from an external USB drive.
