5 Saving, Recalling, and Printing Data
124 Agilent 1000B Series Oscilloscopes User’s Guide
To edit folder/file names
In the folder/file name edit dialog:
• Select the menu item to move the cursor between fields in the
dialog.
• Turn the entry knob to select:
• A character in the filename (when the cursor is in the name field).
• A key (when the cursor is in the keypad field).
• When the cursor is in the keypad field, push the entry knob to:
• Choose an alphanumeric character for the name (and move to the
next name character).
• On “Aa”, change from upper to lower case characters on the keypad.
• On “En”, change from single- byte to multi- byte character entry fields.
• Select the menu item to delete a character from the name.
Figure 50 Editing Folder/File Names in Disk Manager
