3Capturing Data
90 Agilent 1000B Series Oscilloscopes User’s Guide
6 Press Sync and continue pressing the softkey or turn the entry knob
to select what to trigger on:
7 Press Standard to toggle between:
NOTE
Normal Polarity Sync triggers always occur on negative-going horizontal sync pulses. If the
video waveform has positive-going horizontal sync pulses, use the Inverted Polarity
selection.
All Lines Trigger on all lines.
Line Num Trigger on a selected line.
If you select “Line Num”, press the following Line Num
menu item and turn the entry knob to select the line
number.
Odd Field Trigger on an odd field.
Even Field Trigger on an even field.
NTSC Trigger on an NTSC video waveform.
PAL/
SECAM
Trigger on a PAL or SECAM video waveform.
