143
Part 6. Calibrating your capillary column (optional) Columns and Traps
Column calibration procedures
6. To recalibrate or to change calibration mode, press [Mode/Type] to see the
column calibration mode menu.
7. Scroll to Length or Diameter and press [Enter]. The following menu
appears:
8. Scroll to Unretain pk and enter the actual elution time from the run
performed above.
9. When you press [Enter], the GC will estimate the column length or diameter
based on the elution time input and will now use that data for all calculations.
The * indicates the current mode
Available calibration modes
Actual column flow rate, mL/min (input)
Elution time, min (input)
Calc length/Calc diameter:
current estimated column length or
ID based in input
Dimension to be calibrated
To Next Page
