Configure the carrier gas

The GC needs to know what carrier gas is being used.

Procedure: Configuring the carrier gas

1. Press [Config] [Front Inlet] or [Config] [Back Inlet].

2. Press [Mode/Type] to see the carrier gas menu.

3. Scroll to the gas you will use. Press [Enter].

This completes carrier gas configuration. See the Inlets volume for more detail.

Carrier gas type.

Press [Mode/Type] to get menu.
