Agilent Technologies 6890 Series User Manual

84
The Column Oven
Oven capabilities
The oven holds two inlets and two detectors, up to four valves in a heated box
on top of the oven and two valves inside the oven, and either capillary or packed
columns.
Figure 16 Column oven
Capability Range
Temperature range –80°C (liquid N
2
) or –60°C (CO
2
) to the configured limit
Maximum temperature 450°C
Temperature programming Up to six ramps
Maximum run time 999.99 minutes
Temperature ramp rates 0 to 120°C/min, depending on instrument configuration
On/Off
switch
Oven door
latch
