Agilent Technologies 6890 Series - Fault Messages

Messages Part 4. Fault messages
256
Part 4. Fault messages
Table 28 lists the Fault messages for the GC. Most require Agilent service
intervention. Those that users can correct have a page reference for the
corrective procedures.
Table 28 Fault Messages
Fault no. Status message Popup message Run log entry Comments
200 Pneu board FPGA Pneumatics shutdown:
faulty pneumatics board
Not ready:
Pneu board FPGA
201 Pneumatics board Pneumatics shutdown:
faulty pneumatics board
Not ready:
Pneumatics board
202 Hydrogen shutdown Hydrogen safety
shutdown
Not ready:
Hydrogen shutdown
See page 262.
203 Signal DSP faulty Signal DSP faulty Not ready:
Signal DSP faulty
204 Sig DSP ROM broken Sig DSP ROM broke Not ready:
Sig DSP ROM broken
205 Sig DSP RAM broken Sig DSP RAM broken Not ready:
Sig DSP RAM broken
206 Sig DSP registers Sig DSP registers Not ready:
Sig DSP registers
207 Sig DSP data corrupt Sig DSP data corrupt Not ready:
Sig DSP data corrupt
208 0-1 mV out #1 Signal path test failed Not ready:
0-1 mV out #1
209 0-1 mV out #2 Signal path test failed Not ready:
0-1 mV out #2
210 Analog out #1 Signal path test failed Not ready:
Analog out #1
