Part 1. Electronic Pneumatic Control (EPC) Flow and Pressure Control

Detectors

Figure 8 Internal/external plumbing: TCD with EPC

For more detail, see the Detectors volume.

EXTERNAL

pressure

regulator

Reference and

makeup in

Proportional

valves

Pressure

sensors Restrictors

Reference

switching

valve

TCD

Makeup flow

6890 GC
