18
Chapter 1: Outline of the DPS12
■ Entering a numeric value directly (time counter/time field)
You can use the keys on the top panel to directly enter a value for the time counter, and time field on the MAIN
screen. Follow the steps below:
1. Use the [CURSOR] key to move the cursor to a time field.
➸
NOTE :
You do not need this step when you enter the time for the time counter in the MAIN screen.
2. Press the [NUMBER/NAME] key.
The [NUMBER/NAME] key’s LED flashes, and the keys on the top panel function as numeric keys.
3. Use the [CHANNEL SELECT] 1–10 keys to enter a desired number (1–9, 0).
The [CHANNEL SELECT] 1–10 keys function as numeric keys 1–9, 0.
For example, if you wish to enter 1 hour 25 minutes 43 seconds for the time counter or a time field, press
the [CHANNEL SELECT] 1–10 keys in the following order:
→ → →
→ →
4. Press the [NUMBER/NAME] key again.
This time, the [NUMBER/NAME] key functions as an [ENTER] key. The [NUMBER/NAME] key’s LED turns
off, and the entered number is confirmed. If you wish to cancel the entered number, press the [SOLO] key
(which functions as a [CANCEL] key) to go back to the previous display.
■ Using the [JOG] dial to enter characters (character field)
1. Use the [CURSOR] key to move the cursor to a character field.
2. Press the [NUMBER/NAME] key.
The [NUMBER/NAME] key’s LED flashes and an underline appears under the first character in the character
field. This underline indicates that you can enter a character.
3. Rotate the [JOG] dial to select a character to enter.
The following numbers, letters, and symbols can be selected by the [JOG] dial.
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z [ ¥ ] ^ _
¬
a
b c d e f g h i j k l m n o p q r s t u v w x y z { | } ¯
X !
"
# $ % & ' ( ) * + , - . / 0 1 2 3 4 5 6 7 8 9 : ; < = > ? @
