C315 Indoor Monitor Administraor Guide
Parameter Set-up:
•
IP address: enter the web relay IP address.
•
User Name: enter the User name provided by the web relaymanufacturer.
•
Password: enter the password provided by the web relay manufacturer. The
passwords are authenticated via HTTP and you can define the passwords using Http
Get in Action.
•
Web Relay Action: enter the specific web relay action command provided by the web
manufacturer for different actions by the web relay.
•
IP/SIP: enter the relay extension information, which can be an IP address or SIP
account of an intercom device such as an indoor monitor, so that the specific action
command will be sent when unlock is performed on the intercom device, while this
setting is optional. And please refer to the example below: http://
admin:admin@192.168.1.2/state.xml?relayState=2.
16.3
Door Unlock Configuration
16.3.1
Door Unlock by DTMF Code
DTMF codes can be configured on the web Account > Advanced > DTMF interface where
you can set up identical DTMF code on the corresponding intercom devices, which allows
residents to enter the DTMF code on the soft keypad or press DTMF code attached unlock
tab on the screen to unlock the door for visitors etc., during acall.
Parameter Set-up:
•
Type: select DTMF type among four options: Inband, RFC2833, Info+Inband and
Info+RFC2833 according to your need.
