Akuvox C315 Series User Manual

C315 Indoor Monitor Administraor Guide
www.akuvox.com
90
Note
• Please refer to the chapter Relay Switch Setting for the specific DTMF code
setting. Intercom devices involved must be consistent in the DTMF type,
otherwise, DTMF code cannot be applied.
Note
• DoorNum in the HTTP command above refers to the relay number #1 to be
triggered.
• How to Notify DTMF: select among four options: Disable, DTMF, DTMF-Relay,and
Telephone-Event according to your need.
• DTMF Payload: select the payload 96-127 for data transmission identification.
16.3.2 Door Unlock via HTTP Command
You can unlock the door remotely without approaching the device physically for door
access by typing the created HTTP command (URL) on the web browser to trigger the
relay when you are not available by the door for door access. To do this configuration on
web Phone > Relay > Open Relay Via HTTP interface.
Parameter Set-up:
• Status: enable it to allow the relay to be triggered remotely using the HTTP
command.
• Username: enter the device username to be used as a part of the HTTP command to
trigger the local relay.
• Password: enter the device password to be used as part of the HTTP command to
trigger the local relay. Please refer to the following example: http://192.168.35.127/
fcgi/do?action=OpenDoor&UserName=admin&Password=12345&DoorNum=1

Akuvox C315 Series Specifications

General

Brand	Akuvox
Model	C315 Series
Category	Monitor
Language	English
