E18 Door Phone Administrator Guide
Name: Check to select the H264 video codec format for the door phone
video stream. H264 is the video codec by default.
Resolution: select the code resolution for the video quality among four
options:”QCIF”, “CIF”, “VGA”, “4CIF” and “720P” according to your actual
network environment. The default code resolution is 4CIF.
Bitrate: select the video stream bit rate (ranging from 320-2048). The
greater the bitrate, the data transmitted in every second is greater in
amount therefore the video will be clearer. While the default code bitrate
is 2048.
Payload: select the payload type (ranging from 90-118) to configure the
audio codec payload. The pay load between the door phone and the
corresponding intercom device should be identical. The default payload
is 104.
8.6. Configure DTMF Data Transmission
In order to achieve the door access via DTMF code or some other
applications, you are required to properly configure DTMF in order to
establish a DTMF-based data transmission between the door phone and
other intercom device for the third party integration. Path:Account >
Advanced > DTMF
Parameter set-up:
Mode: select DTMF mode among five options: “Inband”, “RFC2833”,
“Info+Inband” and “Info+RFC2833” based on the specific DTMF
To Next Page
