E18 Door Phone Administrator Guide
DTMP Mode is set as 3-digits.
Relay Status: relay status is low by default which means normally
closed(NC) If the relay status is high, then it is in Normally Open
status(NO).
Relay Name: name the relay switch according to your need. For example
you can name the relay switch according to where the relay switch is
located for the convenience.
Note:
Only the external devices connected to the relay switch needs to be
powered by powered adapters as relay switch does not supply
power.
Note:
If DTMF mode is set as “1 Digit DTMF” , you cannot edit DTMF code
in 2~4 Digits DTMF field. And if you set DTMF mode from 2-4 in
2~4 Digits DTMF” field, you can not edit DTMF code in 1 Digit
DTMF field.
10.2.DTMF Code Configuration
DTMF codes can be configured on the door phone web interface and set up
identical DTMF code on the corresponding intercom devices such as indoor
monitor, which allows residents to enter the DTMF code on the soft keypad or
press DTMF code attached unlock tab on the screen to unlock the door for
visitors etc., during a call. Path: Account > Advanced > DTMF.
Parameter Set-up:
