Appendix E Redundancy Object Attributes
Status of the synchronization
(qualification) process.
Qualification InProgress INT GSV If Then
-1 Synchronization (qualification) is not in progress.
0Unsupported
1 - 99 For modules that can measure their completion percentage, the
percent of synchronization (qualification) that is complete.
50 For modules that cannot measure their completion percentage,
synchronization (qualification) is in progress.
100 Synchronization (qualification) is complete.
Mode switch settings of the
controller and its partner match or do
not match.
Mode switchAlarm DINT GSV If Then
0 • The mode switches match
OR
• No partner is present.
1 Mode switches do not match
Position of the mode switchmode
switch of the partner.
Partnermode switch DINT GSV If Then the mode switch is in
0 Unknown
1RUN
2PROG
3REM
Status of the minor faults of the
partner (if the
ModuleRedundancyState indicates
that a partner is present).
PartnerMinorFaults DINT GSV This bit Means this minor fault
1 Power-up fault
3IO fault
4 Problem with an instruction (program)
6 Periodic task overlap (watchdog)
9 Problem with the serial port
10 Low battery or issue with the energy storage module
Mode of the partner. PartnerMode DINT GSV If Then
16#0 Power up
16#1 Program
16#2 Run
16#3 Test
16#4 Faulted
16#5 Run-to-program
16#6 Test-to-program
16#7 Program-to-run
16#8 Test-to-run
16#9 Run-to-test
16#A Program-to-test
16#B Into faulted
16#C Faulted-to-program
For this information Get this attribute Data
Type
GSV/SSV Description
