Chapter 2 Design an Enhanced Redundancy System
Connection from HMI Over a ControlNet Network shows an example of
connecting an HMI to a primary controller over a ControlNet network.
Figure 11 - Connection from HMI Over a ControlNet Network
For an example of how to connect an HMI to a redundant chassis pair over a path
that bridges from an EtherNet/IP network to a ControlNet network, see
Configuration Used to Eliminate Communication Delays on Switchover on
page 37.
CH2 CH1 OK
CH2 CH1 OK
CH2 CH1 OKCH2 CH1 OK
ControlNet
HMI
Redundant Chassis Pair
ControlNet
