156 Rockwell Automation Publication 1441-UM001B-EN-P - September 2012
Chapter 5 Collecting and Reviewing Data
Table 43 - Offroute User Parameters
Parameter Name Description Values/Comments
Change Name Changes the name of the user-defined measurement point.
Select the hierarchy level for which you want to change the name. A
window opens at the bottom of the screen. Use the numeric key pad
to enter a new name and press F2 (OK).
Select Level (default)
Default Locn
Default Point
1 Horiz
Default
Collection The type of data to collect with this measurement. Overall/Signature (default): collect both a magnitude
reading and a signature.
Overall only: collect a magnitude reading only.
Signature only: collect a signature only.
RSS Overall: collect a digital overall measurement.
Display Format The display format of the measurement. Spectrum (default)
Time
Phase
Order
Units The measurement units for the transducer.
The [S] designation refers to a static measurement that you must
manually enter with the numeric key pad. All dynamic measurements
and temperature process points require a transducer to make the
measurement.
Accel (G) (default)
gSE
RPM
A->V (mm/s)
Vel (IPS)
Vel (mm/s)
A->D (mil)
A->D (µm)
V->D (mil)
V-D> (µm)
Disp (mil)
Disp (µm)
Volts
EU’s [S]
Temperature [S]
Current (A) [S]
Pressure (PSI) [S]
Flow (m
3
/s) [S]
Rot. Speed [S]
Linear Displ (mm)
Count [S}
Count Rate [S]
Volts [S]
Accel (G) [S]
Vel. (IPS) [S]
Vel (mm/s) [S]
Disp (mil) [S]
Disp (µm) [S]
Coupling The type of coupling that will be applied to the measurement. AC: couples the input voltage signal.
DC: couples the input voltage signal.
ICP: (default) selects a standard ICP accelerometer
requiring a current source power supply
