Publication 1763-UM001E-EN-P - June 2015
154 Specifications
Agency certification UL Listed Industrial Control Equipment for use in Class 1, Division 2, Hazardous Locations,
Groups A, B, C, D
C-UL Listed Industrial Control Equipment for use in Canada
CE marked for all applicable directives
RCM marked for all applicable acts
EAC certified for: Russian Customs Union TR CU 020/2011 EMC Technical Regulation,
Russian Customs Union TR CU 004/2011 LV Technical Regulation
ESD immunity EN 61000-4-2
4 kV contact, 8 kV air, 4 kV indirect
Radiated RF immunity EN 61000-4-3
10V/m, 26…1000 MHz (alternatively, 80…1000 MHz),
80% amplitude modulation, +900 MHz keyed carrier
Fast transient immunity EN 61000-4-4
2 kV, 5 kHz
communications cable such as EtherNet, RS-232, and RS-485: 1 kV, 5 kHz
Surge transient immunity EN 61000-4-5
Unshielded communications cable: 2 kV CM (common mode), 1 kV DM (differential mode)
Shielded communications cable: 1 kV galvanic gun
I/O: 2 kV CM (common mode), 1 kV DM (differential mode)
AC Power Supply Input: 4 kV CM (common mode), 2 kV DM (differential mode)
DC Power Supply Input: 500V CM (common mode), 500V DM (differential mode)
AC/DC Auxiliary Output: 500V CM (common mode), 500V DM (differential mode)
Conducted RF immunity EN 61000-4-6
10V, 150 kHz…80 MHz
Conducted emissions EN 55011
AC Power Supply Input: 150 kHz…30 MHz
Radiated emissions EN 55011
30…1000 MHz
Line related tests EN 61000-4-11
AC Power Supply Input:
voltage drop: -30% for 10 ms, -60% for 100 ms
voltage interrupt: at voltage greater than -95% for 5 sec.
voltage fluctuation: +10% for 15 minutes, -10% for 15 minutes
DC Power Supply Input:
voltage fluctuation: +20% for 15 minutes, -20% for 15 minutes
General Specifications
Description 1763-
L16AWA L16BWA L16BBB L16DWD
