Specifications 155
MicroLogix 1100 DC Input Power Requirements for 1763-L16BBB Unit
4 8 121620
28
21
14
7
1763-L16BBB and 1763-L16DWD Typical Power Requirements
Calculated Load power (Watts)
I
n
p
u
t
P
o
w
e
r
R
e
q
u
i
r
e
d
a
t
2
4
V
D
C
(
W
a
t
t
s
)
0
Digital Input Specifications
Description 1763-L16AWA 1763-L16BWA, -L16BBB
Inputs 0 through 3
(4 high-speed DC inputs)
Inputs 4 and higher
(6 standard DC inputs)
On-state voltage range 79…132V AC 14…24V DC
(14…26.4V DC (+10%) at
65 °C/149 °F)
(14…30V DC (+25%) at
30 °C/86 °F)
10…24V DC
(10…26.4V DC (+10%) at
65 °C/149 °F)
(10…30V DC (+25%) at
30 °C/86 °F)
Off-State voltage range 0…20V AC 0…5V DC
Operating frequency 47 Hz…63 Hz 0 Hz…20 kHz
0 Hz…40 kHz
(1)
0 Hz…1 kHz
(scan time dependent)
On-state current:
•minimum
•nominal
•maximum
•5.0 mA at 79V AC
•12 mA at 120V AC
•16.0 mA at 132V AC
•2.5 mA at 14V DC
•9.8 mA at 24V DC
•12.0 mA at 30V DC
•2.0 mA at 10V DC
•8.5 mA at 24V DC
•12.0 mA at 30V DC
Off-state leakage current, max. 2.5 mA 1.5 mA
Nominal impedance 12 kΩ at 50 Hz
10 kΩ at 60 Hz
3.1 kΩ 3.1 kΩ
Inrush current (max.) at 120V AC 250 mA Not applicable
(1) OS Series B FRN 4 or later

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
