Allen-Bradley MicroLogix 1100 User Manual

Publication 1763-UM001E-EN-P - June 2015
156 Specifications
Digital Input Specifications for 1763-L16DWD
Description 1763-L16DWD
Inputs 0 through 3
(4 high-speed DC inputs)
Inputs 4 and higher
(6 standard DC inputs)
On-state voltage range 10…24V DC at 65 °C/149 °F)
(10…30V DC at 30 °C/86 °F)
Off-state voltage range 0…5V DC
Operating frequency
0 Hz…40 kHz
(1)
0 Hz…1 kHz
On-state current:
•minimum
•nominal
•maximum
•2.0 mA at 10V DC
•8.5 mA at 24V DC
•12.0 mA at 30V DC
Off-state leakage current 1.5 mA max.
Nominal impedance 2.61 kΩ 3.1 kΩ
Maximum inrush current Not applicable
(1) OS Series B FRN 4 or later
Analog Input Specifications
Description 1763-L16AWA, -L16BWA, -L16BBB, -L16DWD
Voltage input range 0…10.0V DC - 1 LSB
Type of data 10-bit unsigned integer
Input coding (0...10.0V DC - 1 LSB) 0…+1,023
Voltage input impedance 210 kΩ
Input resolution 10 bit
Non-linearity ±1.0% of full scale
Overall accuracy
-20…65 °C (-4…149 °F)
±1.0% of full scale
Voltage input overvoltage protection 10.5V DC
Field wiring to logic isolation Non-isolated with logic

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
