Publication 1763-UM001E-EN-P - June 2015
178 Specifications
Non-linearity (in percent full scale)
< ±0.59%
(2)
< ±0.59%
(2)
Open and short-circuit protection Continuous Continuous
Output protection ±32 mA ±32 mA
(1) Includes offset, gain, non-linearity and repeatability error terms.
(2) Only applicable to Series B I/O modules.
Output Specifications
Specification 1762-IF2OF2 1762-OF4
Valid Input/Output Data Word Formats/Ranges for 1762-IF2OF2
Normal Operating Range Full Scale Range RAW/Proportional Data Scaled-for-PID
0…10V DC 10.5V DC 32,760 16,380
0.0V DC 0 0
4…20 mA 21.0 mA 32,760 16,380
20.0 mA 31,200 15,600
4.0 mA 6240 3120
0.0 mA 0 0
