Allen-Bradley MicroLogix 1100 User Manual

Publication 1763-UM001E-EN-P - June 2015
52 Wiring Your Controller
1763-L16AWA and 1763-L16BWA Output Wiring Diagram
1763-L16BBB Output Wiring Diagram
1763-L16DWD Output Wiring Diagram
L2
L1
+DCa
CR
L2b
-DCa
L1a L1b
L2a
VAC O/0
VDC
VAC O/1
VDC
VAC O/2
VDC
VAC O/3
VDC
VAC O/4
VDC
VAC O/5
VDC
NOT
USED
NOT
USED
L1 L2/N
100-240 VAC
CR
L2d
L1c L1d
L2c
L1e
L2e
-DC
+DC
+DCa +DCc
-DCa
+DCb
-DCb
CR CR
-DCc
VAC O/0
VDC
VAC O/1
VDC
NOT
USED
NOT
USED
DC O/2 O/3
24V+
DC
24V-
O/4 O/5NOT
USED
NOT
USED
+ 24V -
DC IN
CR
+DCa
CR
L2b
-DCa
L1a L1b
L2a
VAC O/0
VDC
VAC O/1
VDC
VAC O/2
VDC
VAC O/3
VDC
VAC O/4
VDC
VAC O/5
VDC
NOT
USED
NOT
USED
CR
L2d
L1c L1d
L2c
L1e
L2e
-DC
+DC
+-
DC IN
-DC
+DC
+-
12/24V

Allen-Bradley MicroLogix 1100 Specifications

General

Processor	32-bit
Programming Software	RSLogix 500
Mounting	DIN rail or panel mount
Power Supply	24V DC
Type	Compact PLC
Digital Inputs	12
Digital Outputs	8
Analog Inputs	4 (depending on model)
Analog Outputs	Optional with expansion module
Programming Language	Ladder Logic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Series	MicroLogix
