Data Output Formats
The format of the decoded messages transmitted from the decoder to the host
computer can vary depending upon the type of bar code scanned and the
configuration of the decoder.
Generic Output Formats
The generic output formats for the decoder are as follows:
Trailer
0 - 10 Characters
Decoded Data
1 - 62 Characters
Code ID Character
0 - 1 Character
Header
0 - 10 Characters
After a good read:
Trailer
0 - 10 Characters
No Read Message
0 - 10 Character
Header
0 - 10 Characters
After a misread with No–Read Recognition enabled:
Reader Address
1 Character
Reader Address
1 Character
Individual Bar Code Symbology Output Formats
Each bar code symbology has a different data format, depending upon which
decoding options have been selected. The exception is Code 128, which has
no decoding options. The output formats for each of the bar code
symbologies are described on the following pages.
