Chapter 6
Programming Via Configuration Bar Code Symbols
6–13
Codabar
Used to enable and disable Codabar.
*Default is Codabar enabled.
Enter
Enable/Disable
Exit
Minimum and Maximum Lengths (Codabar)
The length of a decoded bar code may be checked to see if it matches a set of
predefined (configurable) limits. If the length of the bar code is within these limits, it
is accepted as valid. If the length is outside the limits, a no–read condition exists.
Default minimum length is 1, default maximum length is 32
The length to be checked includes any check characters but does not include
start and stop characters. If you want to check for a specific length, the
minimum and the maximum should be set to the same number. Setting the
maximum less than the minimum (or the minimum more than the maximum) will
cause a syntax error.
Start/Stop Character Transmission (Codabar)
Codabar has the option to either transmit the start and stop
characters with the message or to suppress them from the message.
When suppressed, the start/stop characters are stripped from the
decoded message.
Codabar is the only bar code that has user information contained in
the start and stop characters.
*The default is start/stop character transmission
Enabled
.
Exit
Enter
Enabled
or
Suppressed
Exit
Enter
Min Length =
Number from
Number menu
Max Length =
Number from
Number menu
To Next Page
