Allen-Bradley Series B

Chapter 2
Description of Hardware
4–2
Connect your equipment as shown in Figure 4.1. A step-by-step procedure
follows.
Figure 4.1
Connecting the Decoder to a Host Computer and Display Terminal
Display
Host
I0
Step 2
Step 1
Step 4
Step 3
Step 5
(optional)
How to Connect Your Equipment
