Allen-Bradley Series B

A–B
B
Appendix
B–1
Escape Sequence Summary
Escape Sequence Function Values of <n> Default Page No
Esc - y <n> A Reader Address 0 - 1 Empty
5-37
Esc - y <n> B Good Read Beep Tone 0 - 16 12
5-38
Esc - y <n> C Speaker /LED Control 33, 34, 36, 38, 40 36
5-39
Esc - y <n> D Intercharacter Delay Time 0 - 250 0
5-29
Esc - y <n> F Code Selection 0 - 63 63
5-13
Esc - y <n> G Check Characters
0 - 3, 8 - 11, 16 - 19,
24 -27
0
5-14
Esc - y <n> H UPC/EAN/Codabar / Code 39 Options 0-127 0
5-20
Esc - y <n> I Code ID Character Assignment 1 - 6 -
5-24
Esc - y <n> J Single Read Mode 0 - 1 0
5-31
Esc - y <n> K Enable Next Read 1 -
5-32
Esc - y <n> M I 2-of-5 Length Checking Options 0 - 33 0
5-18
Esc - y <n> N Header 0 - 10 Empty
5-33
Esc - y <n> O Trailer 0 - 10 Empty
5-34
Esc - y <n> P Serial Port Configuration 2 - 127 6
5-26
Esc - y <n> Q
Self Test
Code ID Character TX
No-Read Recognition
0 - 3, 16 - 19 16
5-12
5-25
5-35
Esc - y <n> R Laser Scanning Options 0 - 15 8
5-41
Esc - y <n> S Show Configuration 4 -
5-7
Esc - y <n> T Pulse Speaker 1 - 16 -
5-40
Esc - y <n> U
Minimum and Maximum Length
Checking
1 - 6 -
5-17
Esc - y <n> V Laser Shut Off Delay 0 - 100 30
5-45
Esc - y <n> W Disable Decoding 0 - 1 1
5-9
Esc - y <n> X XON / XOFF 0 - 1 0
5-30
Esc - y <n> Y No Read Message 0 - 10 0
5-36
Esc - y <n> Z Reset/Store Configuration 1 or 5 -
5-10
