Allen-Bradley Series B

Table of Contents
ii
Chapter 5
Determining the <n> Value 5-3
Concatenating Escape Sequences 5-4
Concatenation Rules 5-4
Concatenation Examples 5-5
Getting Started 5-6
Show Configuration Esc - y 4 S 5-7
Reading the Screen 5-7
Show Configuration Syntax 5-8
Show Configuration Example 5-8
Disable Decoding Esc - y <n> W 5-9
Disable Decoding Syntax 5-9
Disable Decoding Example 1 5-9
Disable Decoding Example 2 5-9
Reset Esc - y 1 Z 5-10
Reset Syntax 5-10
Reset Examples 5-10
Store Configuration Esc - y 5 Z 5-11
Store Configuration Syntax 5-11
Store Configuration Example 5-11
ROM/RAM Self Test Esc - y 16 Q 5-12
ROM/RAM Self Test Syntax 5-12
ROM/RAM Self Test Examples 5-12
Code Selection Esc - y <n> F 5-13
Code Selection Syntax 5-13
Code Selection Example 5-13
Check Characters Esc - y <n> G 5-14
Using Check Characters 5-14
Verifying Check Characters 5-14
Transmitting Check Characters 5-15
Selecting the Number of Code 11 Check Characters 5-15
Check Character Syntax 5-16
Check Character Example 5-16
Minimum and Maximum Length 5-17
Minimum and Maximum Length Syntax 5-17
Minimum and Maximum Length Example 5-17
Interleaved 2 of 5 Length Checking Options Esc - y <n> M 5-18
Interleaved 2 of 5 Length Checking Syntax 5-19
Interleaved 2 of 5 Length Checking Examples 5-19
UPC/EAN Options Esc - y <n> H 5-20
UPC/EAN Options Syntax 5-21
UPC/EAN Options Example 5-21
Codabar Options Esc - y 2 H 5-22
Codabar Options Syntax 5-22
Codabar Options Example 5-22
Programming Via Escape
Sequences
