116 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Chapter 4 Programming
Table 24 - 150-SM4 Parameters
Parameter Min/Max Values Default Value Access Units
Number
(1)
Name
X.1 Module Status Bit 0 = Module Ready/Disabled
Bit 1 = Input 1 Status
Bit 2 = Input 2 Status
Bit 3 = Input 3 Status
Bit 4 = Input 4 Status
Bit 5 = Aux 1 Status
Bit 6 = Aux 2 Status
Bit 7 = Aux 3 Status
—R0 = Disabled OFF
1 = Enabled ON
X.2 Input 1 Disable
Start
Coast
Stop Option
Start/Coast
Start/Stop
Dual Ramp
OL Select
Fault
Fault NC
Clear Fault
Emerg Run
Motor Heater
Disable R/W NA
X.3 Input 2
X.4 Input 3
X.5 Input 4
X.6 Aux 1 Config [Normal]
UTS (Up-to-Speed)
Fault
Alarm
Ext Bypass
Ext Brake
DeviceLogix
Aux Control
(2)
Network 1
Network 2
Network 3
Network 4
Fan Control
Normal R/W NA
X.7 Aux 1 Invert Disable
Enable
Disable R/W
X.8 Aux 1 On Delay 0.0…10.0 0.0 R/W seconds
X.9 Aux 1 Off Delay 0.0…10.0 0.0 R/W seconds
X.10 Aux 2 Config Normal
UTS (Up-to-Speed)
Fault
Alarm
Ext Bypass
Ext Brake
DeviceLogix
Aux Control
(2)
Network 1
Network 2
Network 3
Network 4
Fan Control
Normal R/W NA
X.11 Aux 2 Invert Disable
Enable
Disable R/W NA
X.12 Aux 2 On Delay 0.0…10.0 0.0 R/W seconds
X.13 Aux 2 Off Delay 0.0…10.0 0.0 R/W seconds
X.14 Aux 3 Config [Normal]
UTS (Up-to-Speed)
Fault
Alarm
Ext Bypass
Ext Brake
DeviceLogix
Aux Control
(2)
Network 1
Network 2
Network 3
Network 4
Fan Control
Normal R/W NA
X.15 Aux 3 Invert Disable
Enable
Disable R/W NA
X.16 Aux 3 On Delay 0.0…10.0 0.0 R/W seconds
X.17 Aux 3 Off Delay 0.0…10.0 0.0 R/W seconds
X.18 Parameter Mgmt Ready
Factory Default
Ready R/W NA
(1) "X" indicates the port number (07, 08, or 09) the 150-SM4 is connected to the SMC-50 control module. This port number is displayed on the HIM screen below the Allen-Bradley brand logo.
(2) An auxiliary output configured for Aux Control using the AuxX Config parameter is under control of its associated bit form the AuxControl, Parameter 180.
