Allen-Bradley SMC-50 User Manual

Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 203
Parameter Information Appendix A
49 Starting Mode 0/5 2 -Full Voltage
-Current Limit
-[Soft Start]
-Linear
Speed-
(Sensorless)
-Torque Ramp
-Pump Start
Used to program the SMC controller for the type of starting
mode that best fits the application.
Full Voltage
: Apply full voltage to the motor at start.
Current Limit
: Apply limited current for a programmed period
of time.
Soft start: Slowly increase current to load over a programmed
period of time.
Linear Speed
: Increase current to cause a linear acceleration of
the motor.
Torque Ramp: Slowly increase torque generated by motor over
fixed period of time.
Pump Start: Special starting algorithm for pump applications.
R/W
50 Ramp Time Sec 0/1000 10.0 Enables the user the ability to configure the time period during
which the controller will ramp the output voltage.
R/W
51 Initial Torque %LRT 0/90 70 The initial reduced voltage output level for the voltage ramp is
established and adjusted with this parameter.
R/W
52 Max. Torque % 0/300 250 Gives the user ability to configure the maximum torque limit of
a torque ramp during a torque start operation.
R/W
53 Cur Limit Level %FLC 50/600 350 The current limit level that is applied for the ramp time
selected.
R/W
54 Kickstart Time SEC 0/2 0.0 A boost of current is applied to the motor for this programmed
time.
R/W
55 Kickstart Level %LRT 0/90 0 Gives the user the ability to adjust the amount of current boost
applied to the motor during the kickstart period.
R/W
56 Input 1 0/14 4 Disable
Start
Coast
Stop Option
[Start/Coast]
Start/Stop
Reserved
Reserved
Dual Ramp
OL Select
Fault
Fault NC
Clear Fault
Emerg Run
Reserved
Allows the user to select the operation of Terminal 11, Input 1
on the control module.
Disable
: Disable the input - ignores any assertion to Input 1,
Terminal 11.
Start: Initiates a start as set up by the start parameters at Input
1, Terminal 11 (High).
Coast
: Initiates a coast stop.- no current to motor at Input 1,
Terminal 11 (Low).
Stop Option: Initiates a stop maneuver as set up by the
stopping parameters at Input 1 (Low).
[Start/Coast]: if Input 1 = 0 - Stops motor; 1- Initiates a start
as set up by the start parameters
Start/Stop
: if Input 1 = 0- Initiates a stop maneuver as set up
by stopping parameters; 1- Initiates a start as set up by the start
parameters
Dual Ramp: if Input 1 = 0 - Use starting mode 1; 1 - Use
starting mode 2
OL Select: if Input 1 = 0 - Use Motor Overload Class 1; 1 - Use
Motor Overload Class 2
Fault
: A fault condition forced if Input 1= 1.
Fault NC: A fault condition forced if Input 1 = 0.
Clear Fault
: Clear a fault from input 1 Terminal 11 (High).
Emerg Run: Allow motor to run in emergency run mode if
asserted from Input 1, Terminal 11 - does not start motor
(High).
R/W
Table 66 - SMC -50 Parameter List (Continued)
Number Name Unit Min/Max Default Enum Text Description R/W
