Allen-Bradley SMC-50 User Manual

206 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Appendix A Parameter Information
84 Locked Rtr F Lvl %FLC 400/1000 600 The peak phase current to the load that, if exceeded for the time
period defined in Locked Rtr Delay, will signal a fault. The
Locked Rotor bit in the Motor Fault En parameter must be set to
signal a fault.
R/W
85 Locked Rtr F Dly Secs 0.1/100 0.1 The time period that the peak phase current exceeds the Locked
Rtr F Level to signal a fault. The Locked Rotor bit in the Motor
Fault En parameter must be set to signal a fault.
R/W
86 Underload F Lvl %FLC 0/99 0 If phase current drops below this level for the period of time set
in Underload F Dly parameter, an Underload Fault will be
signaled. The Underload bit in the Motor Fault En parameter
must be set to signal a fault.
R/W
87 Underload F Dly Secs 0.1/99 0.1 The time period that the phase current must be below the level
set in the Underload F Level parameter before a underload fault
is signaled. The Underload bit in the Motor Fault En parameter
must be set to signal a fault.
R/W
88 Underload A Lvl %FLC 0/99 0 If phase current drops below this level for the period of time set
in Underload A Dly parameter, an Underload Alarm will be
signaled. The Underload bit in the Motor Alarm En parameter
must be set to signal a alarm.
R/W
89 Underload A Dly Secs 0.1/99 0.1 The time period that the phase current must be below the level
set in the Underload A Level parameter before an Underload
Alarm is signaled. The Underload bit in the Motor Alarm En
parameter must be set to signal a alarm.
R/W
90 MWatts Ov F Lvl MW 0/1000 0.000 If the Real Power exceeds this level for the time period set in
MWatts Ov F Dly parameter, an MWatts Ov fault will be
signaled. The MWatts Ov bit in the Motor Fault En parameter
must be set to signal a fault.
R/W
91 MWatts Ov F Dly Secs 0.1/99 0.1 The time period that Real Power must exceed MWatts Ov F Lvl
to signal a fault. The MWatts Ov bit in the Motor Fault En
parameter must be set to signal fault.
R/W
92 MWatts Ov A Lvl MW 0/1000 0.000 If the Real Power exceeds this level for the time period set in
MWatts Ov A Dly parameter, a MWatts Ov Alarm will be
signaled. The MWatts Ov bit in the Motor Alarm En parameter
must be set to signal an alarm.
R/W
93 MWatts Ov A Dly Secs 0.1/99 0.1 The time period that Real Power must exceed MWatts Ov A Lvl
to signal an alarm. The MWatts Ov bit in the Motor alarm En
parameter must be set to signal an alarm.
R/W
94 MWatts Un F Lvl MW 0/1000 0.000 If the Real Power drops below this level for the time period set
in MWatts Un F Dly parameter, an MWatts Un Fault will be
signalled. The MWatts Un bit in the Motor Fault En parameter
must be set to signal a fault.
R/W
95 MWatts Un F Dly Secs 0.1/99 0.1 The time period that Real Power must drop below MWatts Un F
Lvl to signal a fault. The MWatts Un bit in the Motor Fault En
parameter must be set to signal a fault.
R/W
96 MWatts Un A Lvl MW 0/1000 0.000 If the Real Power drops below this level for the time period set
in MWatts Un A Dly parameter, an MWatts Un Alarm will be
signaled. The MWatts Un bit in the Motor Alarm En parameter
must be set to signal an alarm.
R/W
97 Mwatts Un A Dly Secs 0.1/99 0.1 The time period that Real Power must drop below MWatts Un A
Level to signal an alarm. The MWatts Un bit in the Motor Alarm
En parameter must be set to signal an alarm.
R/W
Table 66 - SMC -50 Parameter List (Continued)
Number Name Unit Min/Max Default Enum Text Description R/W
