Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 91
Programming Chapter 4
Once all parameters are entered, the START-UP folders screen appears.
Review/Modify Parameter Data
1. Display the START UP folder screen.
2. Press the ENTER (#5) key.
3. Select the "Yes" soft key when "Run General Start-Up?" is displayed.
4. Individually review each parameter (required), pressing the ENTER soft
key to move onto the next parameter. If necessary, press the ESC soft key
to review the previous parameter.
TIP If you enter an incorrect value: Press the ESC soft key to return to the
previous screen, then enter the desired value. Use the left arrow soft key to
delete a single digit at a time from the data field to enter the correct digit. If
a group of selections is displayed, the left arrow soft key moves to the
lowest numbered selection.
TIP To modify parameter data, use the procedure outlined in Entering Data into
General Startup on page 90.
