AT-TQ5403 Access Point User’s Guide
55
If you update or change any of these parameters, click the SAVE &
APPLY button to save and update your configuration.
Mode Select the communication protocol to support
(IEEE 802.11b/g, IEEE 802.11b/g/n).
Characters delimited by "/" after IEEE 802.11 are
combinations of supported modes. For example,
IEEE 802.11b/g/n supports b, g, n wireless client
connections.
The factory default is "IEEE 802.11b/g/n".
Channel Select the channel to use. The number of available
channels varies by radio, bandwidth, and country.
When "auto" is selected, this product will scan the
empty channel and automatically select the channel
with less interference. When "auto" is set, the
channel is automatically selected even when
starting up this product. You can check the active
channel the "Monitoring > Status> Radio1 window.
The factory default is "auto".
Bandwidth Select from 20 MHz or 40 MHz to be used.
The factory default is "20 MHz".
Auto Channel
Selection
When "auto" is selected for "channel", set the
candidate for the automatically selected channel. If
checked, it will be a candidate. If it is unchecked, it
will not be a candidate and the channel will not be
used.
By default, all channel candidates are checked.
Also, candidates that can be used change
according to the setting of the "Bandwidth" field.
Tx Power Select the strength of the radio transmit output from
"Max", "High", "Middle", "Low", "Min".
The factory default is "Max".
Table 24. Settings > Radio > Radio1 > Basic Settings Window (Continued)
Item Name Description
