Settings
72
Security Mode: None
When you initially select Settings > VAP/Security > Security, the factory
default security mode of “None” is displayed in the Radio1 > VP0 window.
Refer to Figure 32.
Figure 32. Settings > VAP/Security > Security - “None” Selection Window
The fields are defined in Table 31 with Mode set to “None”.
If you select any of these options for the Security Mode, click the SAVE &
APPLY button to save and update your configuration.
Security Mode: WPA Personal (Pre-Shared Key)
When you select the “WPA Personal” Security Mode, the WPA Personal
window is shown. Refer to Figure 33.
Table 31. Settings > VAP/Security > Security - “None” Selection Window
Item Name Features
Mode None:
Does not perform authentication and encryption. Anyone
can freely connect to VAP.
When choosing “None” for the purpose of preparing a
Hotspot for guest etc., it is necessary to consider the
security of the whole network.
The factory default is “None”.
To Next Page
