Settings
60
If you update or change any of these parameters, click the SAVE &
APPLY button to save and update your configuration.
Mode Select the communication protocol to support (IEEE 802.11a or IEEE
802.11a/n/ac). Characters delimited by "/" after IEEE 802.11 are
combinations of supported modes. For example, "IEEE 802.11a/n/ac"
supports connection of wireless clients of a, n, ac.
The factory default is "IEEE 802.11a/n/ac".
NOTE: When using IEEE 802.11n or IEEE 802.11ac, "Wi-Fi multimedia
(WMM)" on Settings > QoS window must be "Enabled" (default). Refer to
Figure 36 and Table 37 on page 80.
Channel Select the channel to use. The number of available channels varies by
radio, bandwidth, and country.
When "auto" is selected, this product will scan the empty channel and
automatically select the channel with less interference. When "auto" is
set, the channel is automatically selected even when starting up this
product.
You can check the current channel in the Monitoring > Status > Radio2
window.
• Refer to Figure 8 and Table 4 on page 26.
The factory default is "auto".
Bandwidth Select from 20 MHz, 40 MHz, 80 MHz to be used.
The factory default is "20 MHz".
Auto Channel
Selection
When "auto" is selected for "channel", set the candidate for the
automatically selected channel. If checked, it will be a candidate. If it is
unchecked, it will be out of candidate and the channel will not be used.
By clicking on "W52" or “W53” button, you can check or uncheck all the
check boxes of the channel candidate.
By default, all channel candidates are checked. Also, candidates that
can be used change according to the setting of "Bandwidth".
Tx Power Select the strength of the radio transmit output from "Max", "High",
"Middle", "Low", "Min".
The factory default is "Max".
Table 26. Settings > Radio > Radio2 > Basic Settings Window (Continued)
Item Name Description
