AT-TQ5403 Access Point User’s Guide
83
If you update or change any of these parameters, click the SAVE &
APPLY button to save and update your configuration.
cwMin The minimum contention window value is a number that determines
the initial random number range (0 to cwMin). For example, if it can
not be transmitted in the first 0 to 15, random numbers are
generated in the range of 0 to 31 the second time. If it can not be
sent at the second time, the third time range is from 0 to 63. Every
time it can not be transmitted, it will double it to cwMax. If it can not
be sent even if it reaches cwMax, it repeats from 0 to cwMax. It is
reset to cwMin if the frame is sent correctly or the frame is discarded.
This value must be less than or equal to the maximum contention
window value.
You can select 1, 3, 7, 15, 31, 63, 127, 255, 511, 1023. This is one
less than the power of 2.
The defaults are 3 (Data 0), 7 (Data 1), 15 (Data 2), 15 (Data 3).
cwMax Select the maximum contention window value. It must be greater
than or equal to the minimum contention window value.
You can select 1, 3, 7, 15, 31, 63, 127, 255, 511, 1023.
The defaults are 7 (Data 0), 15 (Data 1), 1023 (Data 2),
1023 (Data 3).
TXOP Limit Sets the time that wireless clients can occupy transmission to this
product. The setting range is 0 to 256. The time that can be occupied
is set value × 32 (microseconds).
The defaults are 47 (Data 0), 94 (Data 1), 0 (Data 2), 0 (Data 3).
Table 39. Settings > QoS > - Advanced Settings/Station EDCA Parameters Window
Item Name Description
